Perkins Generator

Description

Our EU Stage V Diesel Generators, available with John Deere, Kubota, FPT, Volvo and Scania Engines and Leroy Somer alternators, provide a power range of 10KVA – 737KVA and is a solution we have developed for the European market with Stage V Emissions as standard. By reducing the emissions to a minimum, this series is classified to the group of environmentally friendly products.

Key Features

1.      Powered by a Kubota V2203-M-E4BG2 Engine.
2.      Optional socket panels are available.
3.      Bunded base tank.
4.      3-way fuel valve for external connection.
5.      Durable, weatherproof, low-noise canopy.

Prime Power (PRP)	17	KVA
Prime Power (PRP)	13.2	KW
Standby Power (ESP)	18	KVA
Standby Power (ESP)	14.5	KW
Voltage – Frequency – Power Factor	400V/50HZ/0.8
Noise Level @ 7m on 100% load	65.1	dBA

Engine Brand	Kubota
Engine Model	V2203-M-E4BG2
Number of Cylinders	4
Fuel Consumptions (100% load)	5.5 L/H

Alternator Brand	Leroy Somer
Alternator Model	LSA40VS4
Excitation system	Shunt

Controller Model	XC7420
Synchronisation	Optional Upgrade

Dry Weight	947	KG
Dimensions	21929631323	mm
Tank Capacity	140	L
